www.nord.com D420
GEARMOTORS
Motor
Power Output
Speed
Output
Torque
Service
Factor
AGMA
Class
Gear
Ratio
Standard
Bearings
Heavy Duty
Bearings (VL)
Model
Type
Weight Dim.
Page
P
n
n
2
T
2
f
B
i
tot
F
R N
F
A N
F
R VL
F
A VL
OHL Thrust OHL Thrust
[hp] [rpm] [Ib-in] [Ib] [Ib] [Ib] [Ib] [lb]
lb
G1000 – Subject to Change Without Notice
(AGMA Class I = f
B
1.0 - 1.39 II = f
B
1.4 - 1.99 III = f
B
≥ 2.0 * = f
B
< 1.0) (Model Type in blue is an Energy Efficient motor)
3.0 43 4416 1.7 II 39.77 1737 2700 2660 2446 SK 9022.1 - 100L/4 123 500
38 4964 1.5 II 44.71 1620 2700 2585 2477 SK 9022.1 - 100LH/4
35 5442 1.4 II 49.01 1499 2700 2511 2477
33 5776 1.3 I 52.02 1400 2700 2453 2518
29 6468 1.2 I 58.25 1143 2700 2318 2531
26 7375 1.0 I 66.42 590 2700 2099 2547
22 8760 0.9 * 78.89 2700 1643 2547
57 3293 3.1 III 29.66 2171 3263 3375 2464 SK 9032.1 - 100L/4 168 508
48 3954 2.5 III 35.61 2248 3263 3375 2540 SK 9032.1 - 100LH/4
45 4225 2.7 III 38.05 2286 3263 3375 2576
42 4481 3.1 III 40.36 2311 3263 3375 2610
36 5296 2.6 III 47.7 2376 3263 3375 2669
34 5545 2.5 III 49.94 2381 3263 3375 2678
29 6570 2.1 III 59.17 2450 3263 3375 2747
27 7115 1.9 II 64.08 2459 3263 3375 2756
22 8429 1.6 II 75.91 2502 3263 3375 2810
20 9346 1.5 II 84.17 2513 3263 3375 2833
18 10382 1.3 I 93.5 2504 3263 3375 2815
15 12300 1.1 I 110.77 2185 3263 3375 2833
11 17626 0.8 * 158.74 3263 2828 2678
31 6184 3.8 III 55.69 6271 9000 6300 4448 SK 9042.1 - 100L/4 271 516
27 7023 3.3 III 63.25 6246 9000 6300 4550 SK 9042.1 - 100LH/4
25 7618 3.3 III 68.61 6228 9000 6300 4644
22 8459 2.9 III 76.18 6197 9000 6300 4727
20 9597 2.6 III 86.43 6152 9000 6300 4835
18 10611 2.3 III 95.56 6107 9000 6300 4914
14 13079 1.6 II 117.79 5974 9000 6300 5058
13 14745 1.7 II 132.79 5868 9000 6300 5090
11 17759 1.4 II 159.94 5636 9000 6300 5213
8.7 21666 1.1 I 195.12 5249 9000 6300 5204
7.3 26095 0.9 * 235.01 4669 9000 6300 5263
17 11370 3.1 III 102.4 8550 10125 8550 8179 SK 9052.1 - 100L/4 437 524
14 13328 3.1 III 120.03 8498 10125 8550 8501 SK 9052.1 - 100LH/4
12 16118 2.0 III 145.16 8397 10125 8550 8890
10 18792 2.3 III 169.24 8280 10125 8550 9194
8.6 22028 1.9 II 198.38 8111 10125 8550 9509
6.9 27433 1.5 II 247.06 7758 10125 8550 9914
5.9 32158 1.3 I 289.61 7369 10125 8550 10125
8.2 22967 3.3 III 206.84 14546 11250 14850 11250 SK 9072.1 - 100L/4 745 532
6.9 27289 2.8 III 245.76 14436 11250 14850 11250 SK 9072.1 - 100LH/4
5.5 34544 2.2 III 311.1 14202 11250 14850 11250 SK 9072.1/32 - 100L/4 820 552
4.4 42847 1.8 II 385.88 13865 11250 14850 11250 SK 9072.1/32 - 100LH/4
3.6 52545 1.4 II 473.22 13361 11250 14850 11250
2.8 66430 1.1 I 598.27 12411 11250 14850 11250
2.2 85227 0.9 * 767.55 10573 11250 14850 11250
3.0 hp
Gearmotors
