www.nord.com C247
GEARMOTORS
Motor
Power Output
Speed
Output
Torque
Service
Factor
AGMA
Class
Gear
Ratio
Standard
Bearings
Heavy Duty
Bearings (VL)
Model
Type
Weight Dim.
Page
P
n
n
2
T
2
f
B
i
tot
F
R N
F
A N
F
R VL
F
A VL
OHL Thrust OHL Thrust
[hp] [rpm] [Ib-in] [Ib] [Ib] [Ib] [Ib] [lb]
lb
G1000 – Subject to Change Without Notice
0.25 hp, 0.33 hp
Gearmotors
0.25 4.1 3905 1.8 II 408.58 3593 3263 5074 4500 SK 3382 - 63L/4 115 338
3.5 4613 1.7 II 482.56 3551 3263 5045 4500
2.9 5583 1.6 II 584.13 3479 3263 4993 4500
2.3 6945 1.2 I 726.61 3353 3263 4907 4500
2.1 7727 1.2 I 808.42 3265 3263 4847 4500
1.8 8784 0.8 * 919.00 3128 3263 4754 4500
1.6 8059 1.0 I 1067.99 3224 3263 4820 4500 SK 3282/12 - 63L/4 120 374
1.3 10082 0.8 * 1335.98 2921 3263 4624 4500
4.9 2572 6.2 III 340.87 4961 4950 6908 6750 SK 4282/12 - 63L/4 153 374
4.1 3093 5.1 III 409.92 4952 4950 6901 6750
3 4215 3.8 III 558.54 4925 4950 6883 6750
2.4 5274 3.0 III 698.96 4892 4950 6858 6750
1.9 6590 2.4 III 873.31 4840 4950 6822 6750
1.5 8382 1.9 II 1110.82 4750 4950 6757 6750
1.3 10139 1.6 II 1343.53 4637 4950 6678 6750
0.33 403 52 9.2 III 4.24 509 812 1125 1890 SK 0182NB - 71S/4 21 312
320 66 9.1 III 5.34 549 893 1125 1890
269 78 9.1 III 6.35 581 961 1125 1890
236 90 8.1 III 7.26 603 1015 1125 1890
198 107 8.1 III 8.64 637 1091 1125 1890
180 117 8.1 III 9.49 657 1136 1125 1890
147 144 6.8 III 11.66 700 1148 1125 1890
124 171 5.7 III 13.84 740 1148 1125 1890
103 204 4.3 III 16.53 779 1148 1125 1890
115 184 3.6 III 14.92 749 1148 1125 1890
91 232 3.6 III 18.79 803 1148 1125 1890
77 276 3.5 III 22.35 846 1148 1125 1890
70 303 3.4 III 24.55 871 1148 1125 1890
59 360 2.7 III 29.13 916 1148 1125 1890
54 393 2.1 III 31.81 938 1148 1125 1890
49 430 2.1 III 34.80 965 1148 1125 1890
45 466 1.9 II 37.73 983 1148 1125 1890
41 517 1.5 II 41.85 1006 1148 1125 1890
34 613 1.4 II 49.65 1058 1148 1125 1890
29 733 1.3 I 59.33 1103 1148 1125 1890
42 499 2.9 III 40.38 986 1125 1654 1125 SK 0282NB - 71S/4 30 318
39 546 2.7 III 44.22 1010 1125 1652 1125
33 638 2.0 III 51.64 1055 1125 1647 1125
30 699 2.0 III 56.55 1082 1125 1643 1125
26 815 1.5 II 65.99 1127 1125 1634 1125
22 981 1.2 I 79.40 1141 1125 1618 1125
20 1059 1.2 I 85.72 1127 1125 1611 1125
17 1274 0.9 * 103.12 1091 1125 1584 1125
357 59 12.6 III 4.79 574 1042 1607 1609 SK 1282 - 71S/4 43 330
313 68 12.2 III 5.47 599 1105 1672 1609
266 79 11.8 III 6.43 630 1179 1751 1609
236 89 11.4 III 7.24 657 1242 1814 1609
208 101 12.6 III 8.21 684 1314 1888 1609
208 102 10.9 III 8.24 684 1314 1888 1609
186 113 11.8 III 9.18 709 1373 1946 1609
165 128 11.4 III 10.34 736 1442 2016 1609
(AGMA Class I = f
B
1.0 - 1.39 II = f
B
1.4 - 1.99 III = f
B
≥ 2.0 * = f
B
< 1.0)
