www.nord.com B120
GEARMOTORS
G1000 – Subject to Change Without Notice
Motor
Power Output
Speed
Output
Torque
Service
Factor
AGMA
Class
Gear
Ratio
Standard
Bearings
Heavy Duty
Bearings (VL)
Model
Type
Weight Dim.
Page
P
n
n
2
T
2
f
B
i
tot
F
R N
F
A N
F
R VL
F
A VL
OHL Thrust OHL Thrust
[hp] [rpm] [Ib-in] [Ib] [Ib] [Ib] [Ib] [lb]
(AGMA Class I = f
B
1.0 - 1.39 II = f
B
1.4 - 1.99 III = f
B
≥ 2.0 * = f
B
< 1.0) (Model Type in blue is an Energy Efficient motor)
lb
30 1415 1336 1.8 II 1.24 1148 SK 51E - 180LX/4 329 164
1219 1551 1.7 II 1.44 1213 SK 51E - 180LH/4
1155 1637 1.7 II 1.52 1242
1070 1767 1.6 II 1.64 1280
964 1961 1.5 II 1.82 1334
852 2219 1.5 II 2.06 1402
702 2693 1.4 II 2.50 1514
614 3081 1.3 I 2.86 1595
530 3566 1.2 I 3.31 1694
631 2995 2.6 III 2.78 1438 2363 3776 3812 SK 52 - 180LX/4 415 197
543 3480 2.4 III 3.23 1490 2471 3796 3960 SK 52 - 180LH/4
516 3663 2.4 III 3.40 1505 2507 3800 4005
478 3954 2.4 III 3.67 1530 2558 3798 4070
430 4395 2.3 III 4.08 1564 2635 3782 4169
401 4719 2.4 III 4.38 1622 2763 3989 4284
381 4966 2.1 III 4.61 1602 2716 3740 4277
345 5473 2.2 III 5.08 1672 2878 3967 4430
313 6033 1.7 II 5.60 1656 2835 3614 4453
303 6238 2.0 III 5.79 1712 2966 3913 4552
288 6561 2.0 III 6.09 1744 3029 3958 4619
273 6916 1.9 II 6.42 1748 3029 3827 4649
241 7832 1.8 II 7.27 1778 3123 3708 4763
228 8295 1.7 II 7.70 1816 3184 3760 4856
199 9513 1.6 II 8.83 1537 3220 3447 4932
166 11398 1.4 II 10.58 1148 3350 3231 5110
130 14490 1.1 I 13.45 554 3503 2898 5371
125 15082 1.1 I 14.00 2428 5319
99 19187 0.9 * 17.81 1784 5537
90 21115 0.8 * 19.60 1427 5600
385 4912 3.3 III 4.56 4223 1796 5056 3938 SK 62 - 180LX/4 540 203
332 5699 2.9 III 5.29 4309 1834 5173 4066 SK 62 - 180LH/4
276 6841 2.5 III 6.35 4415 1872 5290 4226
232 8144 3.3 III 7.56 4529 1973 5573 4442
200 9459 2.8 III 8.78 4505 2000 5657 4579
166 11365 2.4 III 10.55 4462 2018 5720 4721
151 12486 2.2 III 11.59 4430 2068 5848 4844
126 14996 1.8 II 13.92 4354 2068 5855 4970
111 17021 1.6 II 15.80 4280 2052 5814 5049
97 19542 1.4 II 18.14 4174 2030 5726 5123
101 18713 1.5 II 17.37 4210 1967 5578 5018 SK 63 - 180LX/4 536 206
84 22375 1.3 I 20.77 4032 1946 5528 5139 SK 63 - 180LH/4
80 23679 1.2 I 21.98 3958 1854 5267 5083
67 28311 1.0 I 26.28 3647 1798 5081 5173
57 33299 1.0 I 30.91 3206 1654 4651 5148
49 38901 0.8 * 36.11 2513 1465 4037 5074
140 13488 2.7 III 12.52 5526 2034 7423 5985 SK 72 - 180LX/4 692 209
122 15438 2.3 III 14.33 5573 2041 7533 6149 SK 72 - 180LH/4
104 18163 2.0 III 16.86 5609 2039 7632 6309
81 23399 1.5 II 21.72 5564 1996 7655 6548
81 23313 1.7 II 21.64 5400 1933 7475 6453
61 30843 1.2 I 28.63 5346 1881 7477 6739
30 hp
Gearmotors
