www.nord.com B124
GEARMOTORS
G1000 – Subject to Change Without Notice
Motor
Power Output
Speed
Output
Torque
Service
Factor
AGMA
Class
Gear
Ratio
Standard
Bearings
Heavy Duty
Bearings (VL)
Model
Type
Weight Dim.
Page
P
n
n
2
T
2
f
B
i
tot
F
R N
F
A N
F
R VL
F
A VL
OHL Thrust OHL Thrust
[hp] [rpm] [Ib-in] [Ib] [Ib] [Ib] [Ib] [lb]
(AGMA Class I = f
B
1.0 - 1.39 II = f
B
1.4 - 1.99 III = f
B
≥ 2.0 * = f
B
< 1.0) (Model Type in blue is an Energy Efficient motor)
lb
60 430 8802 2.7 III 4.12 3814 1391 5162 4199 SK 72 - 225M/4 994 209
365 10361 2.5 III 4.85 3839 1388 5220 4316 SK 72 - 225MH/4
316 11963 2.1 III 5.60 3825 1375 5245 4406
276 13715 1.8 II 6.42 3789 1357 5231 4491
255 14848 2.6 III 6.95 4059 1463 5560 4698
216 17497 2.4 III 8.19 4003 1427 5535 4797
187 20210 2.1 III 9.46 3915 1382 5470 4874
163 23158 1.8 II 10.84 3791 1328 5348 4921
141 26747 1.3 I 12.52 3798 1316 5409 5056
124 30614 1.2 I 14.33 3605 1224 5182 5074
98 38454 1.2 I 18.00 2907 941 4399 4946 SK 73 - 225M/4 1017 212
86 44051 1.0 I 20.62 2448 752 3904 4874 SK 73 - 225MH/4
76 49862 0.9 * 23.34 1847 554 3337 4775
286 13224 2.9 III 6.19 7349 2939 9126 7335 SK 82 - 225M/4 1235 215
240 15788 3.5 III 7.39 7767 3105 9641 7760 SK 82 - 225MH/4
201 18842 3.1 III 8.82 7940 3170 9968 8026
171 22068 2.8 III 10.33 8060 3200 10206 8273
149 25294 2.5 III 11.84 8134 3231 10310 8474
124 30528 1.9 II 14.29 8251 3247 10490 8766
107 35378 1.6 II 16.56 8251 3231 10517 8951
84 44948 1.6 II 21.04 7947 3080 10276 9124 SK 83 - 225M/4 1252 218
72 52169 1.4 II 24.42 7722 2959 10031 9227 SK 83 - 225MH/4
63 59881 1.2 I 28.03 7385 2806 9682 9241
54 69474 1.1 I 32.52 6919 2590 9167 9227
40 94811 0.8 * 44.38 5328 1924 7387 8951
143 26469 3.5 III 12.39 13505 6057 14796 13100 SK 92 - 225M/4 1623 221
123 30678 3.1 III 14.36 13865 6203 15161 13527 SK 92 - 225MH/4
107 35185 2.7 III 16.47 14180 6325 15458 13923
93 40847 2.6 III 19.12 14391 6406 15644 14308 SK 93 - 225M/4 1647 224
77 49072 2.2 III 22.97 14650 6509 15887 14798 SK 93 - 225MH/4
65 57788 1.9 II 27.05 14504 6572 16038 15208
57 66760 1.6 II 31.25 14324 6584 15991 15552
45 84471 1.3 I 39.54 13887 6521 15732 16009
38 99489 1.1 I 46.57 13421 6377 15311 16241
33 114935 0.9 * 53.80 12841 6185 14706 16371
29 131662 0.9 * 61.63 12078 5931 13905 16452
84 45269 3.9 III 21.19 22124 10226 21834 17559 SK 103 - 225M/4 2130 230
70 54049 3.3 III 25.30 22813 10544 22655 18277 SK 103 - 225MH/4
60 63278 2.8 III 29.62 22727 10798 23312 18842
47 80967 2.2 III 37.90 22520 11169 24311 19643
39 96669 1.8 II 45.25 22293 11313 24939 20153
33 113183 1.6 II 52.98 22005 11405 25344 20576
29 129697 1.4 II 60.71 21670 11423 25360 20878
25 150355 1.2 I 70.38 21175 11387 25085 21112
60 hp
Gearmotors
