West Control Solutions DataVU 7 - Manual (Page 71)

71
5 Memory Presentation (History)
Search
If you select “Search”, the dialog window for entering the date will be shown.
h Select the date and time, and use OK to close the dialog.
If the date that was entered is in the History memory, the cursor will move to
this position and the data will be shown.
Numerical
measurement
display This function decides whether the MAX or MIN values are shown in the
“Numerical measurement display”. Min or Max values arise when more
measurements are recorded than are displayed. This will be the case if “Min/
Max recording” is activated in a group operating mode.
Channel step-
on This function activates the scaling display. Repeatedly activating the function
steps through the scaling for the channels within the group, and then blanks it
out again.
Close memory
presentation This function starts the presentation of the data that are available in the
internal main memory of the instrument.
