Page 131

131
18 Configuration - Groups
18.5 Diagram View
Overview
Perforation
If perforation is switched on, then the perforated margin – familiar from chart
recorders – appears in the curve display, on the left-hand and right-hand
edges of the screen. A precondition for this is, however, that the display of the
binary traces is switched out of display.
H
It is also possible to alter some parameters in the visualization
Curves or Binary using the
symbol, without having to alter the
configuration.
Perforation/punched edges is switched on.
Diagram header is switched on.
Binary channels are hidden.
