103
12 Configuration - Screen
Show binary
image This parameter determines whether binary screen presentation may be called
up in the Visualization menu.
In the presentation, the analog channels are dispensed with, only the binary
channels are made visible.
Show
reports This parameter determines whether report presentation may be called up in
the Visualization menu.
Each report is run on all analog channels of a group. Each group has its own
configurable report.
Show
alarms This parameter determines whether alarm messages are displayed in the
“status & title bar”.
Display
after reset This parameter determines which visualization or representation is shown on
the screen after switch-on (connecting the supply voltage).
Group
after reset This parameter determines which group is displayed on the screen in “Display
after a reset” (visualization after switch-on).
Thousands
separator This parameter determines whether a thousands separator is inserted for the
visualization of the counter and integrator counts.
Bar code
-> current batch This parameter determines whether the visualization of the current batch data
will be started automatically when acquiring a bar code with a connected
barcode reader.
Yes Binary screen presentation can be called up.
Yes Report presentation can be called up.
Yes Alarms are displayed.
Last display The display that was active before switch-off is
restarted.
Curve diagram ...
Batch diagram A specific visualization is to be displayed.
Yes Thousands separator is inserted.
Separator
Yes The data for the current batch will
appear in the display automatically.
