23 Configuration – Batches/Plants
Bin. combined
text
One of 128 device-internal batch texts is used. The
selection is made through up to 6 binary signals.
Plant name
The plant name is shown.
Batch No.
plant 1 — 3
One of three batch numbers is used together with an
additional text ("Fixed text"). The batch number is
incremented by one at the end of a batch. It can be
preset in the Parameterization menu.
Batch start
Start (date and time) of a batch report.
Batch end
End (date and time) of a batch report.
Batch duration
The time difference between batch start and batch end.
If, for instance, 2 binary signals are active, then 4 texts
can be inserted. If all 6 binary signals are active, then 64
different texts can be inserted. Binary linkage 1 has the
value 2
0
, binary linkage 2 has the value 2
1
, and so on.
B6
B5
B4
B3
B2
B1
yes
0
0
0
0
0
0
0
0
0
0
0
0
1
1
0
0
0
0
1
0
2
0
0
0
0
1
1
3
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
1
1
1
1
0
0
60
1
1
1
1
0
1
61
1
1
1
1
1
0
62
1
1
1
1
1
1
63
0 = set to inactive, or no active signal
1 = not set to inactive, and signal is active
The “Start at text” parameter is added to the text column
for the output of the batch text.
