173
24 Configuration - Date and Time
24.1 Time Synch. … Daylight Saving Time
Overview
Time synch. This parameter can be used to influence the time setting for the paperless
recorder. When used in conjunction with a binary signal it can thus ensure that
several recorders are synchronized to the same time.
Synch. at batch This parameter determines whether the time synchronization can also be
activated while batch reporting is in progress.
Inactive No synchronization takes place.
Binary I/O Select the signal that is to be used to activate the
synchronization.
The time is synchronized with the transition from Low to
High
(min. pulse duration = 125 ms)
.
The seconds are decisive when changing the time. The
time is advanced or retarded by a maximum of
±30 seconds.
Example: 12:55:29 -> 12:55:00
12:55:30 -> 12:56:00
No No synchronization will take place while a batch report is
active.
Yes Time synchronization will be carried out, even if a batch
report is active.
