4 Visualization
4.11 Comment Entry
This function can be used to enter a text (max. length 31 characters) that is
entered in the event list when the input is completed.
In curve presentation (in the displayed group), the text entry is marked by a
pencil symbol.
v Chapter 6 "Alarm and Event Lists"
v Chapter 4.3 "Curve Presentation"
v Chapter 4.11 "Comment Entry"
The text can now be found in the event list, under the heading “All events”, but
also under the corresponding batch.
H
If batches are used (parameter: Device manager 
Configuration  Batches/plants  Gen. plant parameters 
Number of plants is larger than 0), then the groups have a fixed
assignment to the batches.
Plant number Group Plant (batch)
0 1 … 9 None
1 1 … 9 1
2 1 … 3
4 … 6
7 … 9 1
2
Not assigned
3 1 … 3
4 … 6
7 … 9 1
2
3
