ProVU4 Controller, Profiler & Recorder/Controller - Product Manual
59407, Issue 1 – March 2008 Modbus Parameters Page 95
Parameter Name Modbus Address Access Values
(Dec) (Hex)
16 Event 2 AND Alarm 2. Direct Acting
17 Event 2 AND Alarm 2. Reverse Acting
18 Event 3 AND Alarm 3. Direct Acting
19 Event 3 AND Alarm 3. Reverse Acting
20 Event 4 AND Alarm 4. Direct Acting
21 Event 4 AND Alarm 4. Reverse Acting
22 Event 5 AND Alarm 5. Direct Acting
23 Event 5 AND Alarm 5. Reverse Acting
Output 3 Retransmit
Minimum 2211 0x08A3 R/W Limited by input range maximum/minimum
Output 3 Retransmit
Maximum 2212 0x08A4 R/W Limited by input range maximum/minimum
Option Slot 4 Parameters
Parameter Name Modbus Address Access Values
(Dec) (Hex)
Value Module Fitted In Slot 4
0 None Fitted
1 Quad Relay
Option Slot 4
Module Type 2222 0x08AE RO
255 Error (unrecognised module)
Value Digital Output 4A, 4B, 4C & 4D Status
0 All outputs inactive
Bit 0 Output 4A Active
Bit 1 Output 4B Active
Bit 2 Output 4C Active
Digital Output 4
Status 2223 0x08AF RO
Bit 3 Output 4D Active
Value Digital Output 4A Function
0 Disabled
1 Primary Output Power
2 Secondary Output Power
3 Alarm
Digital Output 4A
Function 2230 0x08B6 R/W
4 Alarm and Event
Value Digital Output 4B Function
0 Disabled
1 Primary Output Power
2 Secondary Output Power
3 Alarm
Digital Output 4B
Function 2231 0x08B7 R/W
4 Alarm and Event
