ProVU4 Controller, Profiler & Recorder/Controller - Product Manual
Page 104
Modbus Parameters
59407, Issue 1 – March 2008
Parameter Name
Modbus Address
Access
Values
(Dec)
(Hex)
Value
Alarm 3 Type
0
Process High Alarm
1
Process Low Alarm
2
Deviation Alarm (SP-PV)
3
Band Alarm
4
Loop Alarm
5
Input/Sensor Break Alarm
6
Auxiliary Input A Break Alarm
Alarm 3 Type
6176
0x1820
R/W
7
Auxiliary Input B Break Alarm
Alarm 3 Value
6177
0x1821
R/W
Limited by the input range maximum and minimum for
Alarm types 0 and 1. Limited by the input span for
alarm types 2 and 3. Not used for alarms 4 to 7.
Alarm 3 Hysteresis
6178
0x1822
R/W
Limited by the input span
Value
Alarm 3 Inhibit Enable
0
Disabled
Alarm 3 Inhibit
Enable/disable
6179
0x1823
R/W
1
Enabled
Value
Alarm 3 Status
0
Inactive
Alarm 3 Status
6180
0x1824
RO
1
Active
Value
Alarm 3 Inhibit Status
0
Not Inhibited
Alarm 3 Inhibit
Status
6181
0x1825
RO
1
Inhibited
Value
Alarm 4 Type
0
Process High Alarm
1
Process Low Alarm
2
Deviation Alarm (SP-PV)
3
Band Alarm
4
Loop Alarm
5
Input/Sensor Break Alarm
6
Auxiliary Input A Break Alarm
Alarm 4 Type
6192
0x1830
R/W
7
Auxiliary Input B Break Alarm
Alarm 4 Value
6193
0x1831
R/W
Limited by the input range maximum and minimum for
Alarm types 0 and 1. Limited by the input span for
alarm types 2 and 3. Not used for alarms 4 to 7.
Alarm 4 Hysteresis
6194
0x1832
R/W
Limited by the input span
Value
Alarm 4 Inhibit Enable
0
Disabled
Alarm 4 Inhibit
Enable/disable
6195
0x1833
R/W
1
Enabled
Value
Alarm 4 Status
0
Inactive
Alarm 4 Status
6196
0x1834
RO
1
Active
Value
Alarm 4 Inhibit Status
0
Not Inhibited
Alarm 4 Inhibit
Status
6197
0x1835
RO
1
Inhibited
