Hold Release Time

The time of day (hh:mm:ss) when a Hold Segment will release if the

Release Type is Time Of Day. Release occurs at the next
occurrence of this time.

Times To Repeat
Sequence

The number of times the entire sequence of profiles should run. – if

the last segment is Repeat Sequence Then End.

Segment End Type

 The action taken after the profile ends normally. From: Control

outputs off; Maintain last profile setpoint; Use controller setpoint.

Select Profile To
Join

 Choose a profile to join to from the list provided – if the last

segment type is Join. The selected profile will start immediately the
current profile ends.

Segment Details

(Cont….)

Segment Events

 Select the event(s) to be active during this segment. For end

segments, events selected to be active stay on until the unit exits
from profiler mode or a new profile runs.

Edit A Profile Header

 Choose the profile to be edited from the list of names is provided,

then alter any values as required – The profile header details are as
shown in “Create A Profile” above
.

Edit A Profile Segment

 Choose the profile, then the segment to be edited from the lists

provided. Alter any values as required – The profile segment details
are as shown in “Create A Profile” above
. Note: The last segment
type can only be set to Join, End or Repeat Sequence Then End.

Insert A Segment

 Choose the profile, then the new segment’s position from the lists

provided – Enter the new segments values as required – The profile
segment details are as shown in “Create A Profile” above
. Note: The
new segments type cannot be set to Join, End or Repeat Sequence
Then End.

Delete A Segment

 Choose the profile, then the segment to be deleted from the lists

provided. End, Join or Repeat segments cannot be deleted.

Delete A Profile

 Choose the profile to be deleted from the list of names is provided.

The user is then prompted confirm that it should be deleted.

Delete All Profiles

 Deletes all profiles from memory. The user is prompted to confirm

that all profiles should be deleted.

Caution:

Use with care!

Profiler Control Menu

Table 21. Profiler Control Menu Screens

Profiler Menu:

Profile Control

If a profile is running, choose from: Do Nothing, Abort Profile (end
immediately); or Jump to Next Profile Segment, Hold Profile or
Release Hold.
If no profile running, choose from: Do Nothing, Run Profile or End
Profile Control (Return to normal controller operation).

Select Profile To Run

Choose the profile to run from the list of names is provided. The
profile name and run status is then confirmed.
