background image

ProVU4 Controller, Profiler & Recorder/Controller - Product Manual

Page 94

Modbus Parameters

59407, Issue 1 – March 2008

Parameter Name

Modbus Address

Access

Values

(Dec)

(Hex)

14

OR of Alarm 1, 2, 3, or 4. Direct

15

OR of Alarm 1, 2, 3, or 4. Reverse

16

OR of Alarm 1, 2, 3, 4 or 5. Direct

17

OR of Alarm 1, 2, 3, 4 or 5. Reverse

Value

Output 3 or 3A Event/Alarm Selection

0

Event 1. Direct Acting

1

Event 1. Reverse Acting

2

Event 2. Direct Acting

3

Event 2. Reverse Acting

4

Event 3. Direct Acting

5

Event 3. Reverse Acting

6

Event 4. Direct Acting

7

Event 4. Reverse Acting

8

Event 5. Direct Acting

9

Event 5. Reverse Acting

10

Profile Running. Direct Acting

11

Profile Running. Reverse Acting

12

End of Profile. Direct Acting

13

End of Profile. Reverse Acting

14

Event 1 AND Alarm 1. Direct Acting

15

Event 1 AND Alarm 1. Reverse Acting

16

Event 2 AND Alarm 2. Direct Acting

17

Event 2 AND Alarm 2. Reverse Acting

18

Event 3 AND Alarm 3. Direct Acting

19

Event 3 AND Alarm 3. Reverse Acting

20

Event 4 AND Alarm 4. Direct Acting

21

Event 4 AND Alarm 4. Reverse Acting

22

Event 5 AND Alarm 5. Direct Acting

Output 3 or 3A
Event And Alarm
Selection

2209

0x08A1

R/W

23

Event 5 AND Alarm 5. Reverse Acting

Value

Output 3B Event/Alarm Selection

0

Event 1. Direct Acting

1

Event 1. Reverse Acting

2

Event 2. Direct Acting

3

Event 2. Reverse Acting

4

Event 3. Direct Acting

5

Event 3. Reverse Acting

6

Event 4. Direct Acting

7

Event 4. Reverse Acting

8

Event 5. Direct Acting

9

Event 5. Reverse Acting

10

Profile Running. Direct Acting

11

Profile Running. Reverse Acting

12

End of Profile. Direct Acting

13

End of Profile. Reverse Acting

14

Event 1 AND Alarm 1. Direct Acting

Output 3B Event
And Alarm Selection

2210

0x08A2

R/W

15

Event 1 AND Alarm 1. Reverse Acting
