ProVU4 Controller, Profiler & Recorder/Controller - Product Manual
Page 88 Modbus Parameters 59407, Issue 1 – March 2008
Parameter Name Modbus Address Access Values
(Dec) (Hex)
12 OR of Alarm 1, 2, or 3. Direct
13 OR of Alarm 1, 2, or 3. Reverse
14 OR of Alarm 1, 2, 3, or 4. Direct
15 OR of Alarm 1, 2, 3, or 4. Reverse
16 OR of Alarm 1, 2, 3, 4 or 5. Direct
17 OR of Alarm 1, 2, 3, 4 or 5. Reverse
Value Output 1 Event And Alarm Selection
0 Event 1. Direct Acting
1 Event 1. Reverse Acting
2 Event 2. Direct Acting
3 Event 2. Reverse Acting
4 Event 3. Direct Acting
5 Event 3. Reverse Acting
6 Event 4. Direct Acting
7 Event 4. Reverse Acting
8 Event 5. Direct Acting
9 Event 5. Reverse Acting
10 Profile Running. Direct Acting
11 Profile Running. Reverse Acting
12 End of Profile. Direct Acting
13 End of Profile. Reverse Acting
14 Event 1 AND Alarm 1. Direct Acting
15 Event 1 AND Alarm 1. Reverse Acting
16 Event 2 AND Alarm 2. Direct Acting
17 Event 2 AND Alarm 2. Reverse Acting
18 Event 3 AND Alarm 3. Direct Acting
19 Event 3 AND Alarm 3. Reverse Acting
20 Event 4 AND Alarm 4. Direct Acting
21 Event 4 AND Alarm 4. Reverse Acting
22 Event 5 AND Alarm 5. Direct Acting
Output 1 Event And
Alarm Selection 2150 0x0866 R/W
23 Event 5 AND Alarm 5. Reverse Acting
Output 1 Retransmit
Minimum 2152 0x0868 R/W Limited by input range maximum and minimum
Output 1 Retransmit
Maximum 2153 0x0869 R/W Limited by input range maximum and minimum
Note:
Digital Outputs are Relays, SSR Drivers or Triacs. Linear Outputs are mA or VDC
