ProVU4 Controller, Profiler & Recorder/Controller - Product Manual
Page 108
Modbus Parameters
59407, Issue 1 – March 2008
Parameter Name
Modbus Address
Access
Values
(Dec)
(Hex)
Value
Day Of Week
1
Monday
2
Tuesday
3
Wednesday
4
Thursday
5
Friday
6
Saturday
Day Of The Week
7872
0x1EC0
R/W
7
Sunday
Display Parameters
Parameter Name
Modbus Address
Access
Values
(Dec)
(Hex)
LED 1 Label
7660
0x1DEC
R/W
LED 2 Label
7661
0x1DED
R/W
LED 3 Label
7662
0x1DEE
R/W
LED 4 Label
7663
0x1DEF
R/W
5 ASCII characters, which can re read or written using
Modbus functions 16 or 23. Valid characters are 0 to
9, a to z, A to Z, plus ( ) - and _.
Defaults: 1 = PRI (Primary); 2 = SEC (Secondary);
3 = TUNE (Tuning); 4 = ALARM (Alarm)
Value
LED 1 Usage
0
Primary Control
1
Secondary Control
2
Tuning
3
Any Alarm
4
Alarm 1
5
Alarm 2
6
Alarm 3
7
Alarm 4
8
Alarm 5
9
Event 1
10
Event 2
11
Event 3
12
Event 4
13
Event 5
14
Any Event
15
Manual Control
16
Profile Running
LED 1 Usage
7664
0x1DF0
R/W
17
Profile Ended
Value
LED 2 Usage
0
Primary Control
1
Secondary Control
2
Tuning
3
Any Alarm
4
Alarm 1
5
Alarm 2
6
Alarm 3
LED 2 Usage
7665
0x1DF1
R/W
7
Alarm 4
