ProVU4 Controller, Profiler & Recorder/Controller - Product Manual
59407, Issue 1 – March 2008 Specifications Page 173
DC Linear Input
DC Linear Types & Ranges
Input
Type Ranges Input
Type Ranges
mA DC 0 to 20mA 4 to 20mA 0 to 5V 1 to 5V
mV DC 0 to 50mV 10 to 50mV
V DC
2 to 10V 0 to 10V
DC Linear Performance
Display Scaling:
Scalable up to –9999 to 10000 for any DC Linear input type.
Minimum Span:
100 display units.
Decimal Point
Display:
Decimal point selectable from 0 to 3 places, but limits to 5 display digits
(e.g. values > 99.9 have no more than 2 decimal places).
DC Input Multi-Point
Linearization: Up to 15 scaling values can be defined anywhere between 0.1 and 100%
of input.
Measurement
Accuracy: 0.1% of span 1LSD.
Maximum Overload: 1A on mA input terminals, 30V on voltage input terminals.
Sensor Break
Protection: Applicable for 4 to 20mA, 1 to 5V and 2 to 10V ranges only.
Break detected within two seconds. Process Control outputs go to the
pre-set power value. Low and Senor Break Alarms operate.
Auxiliary Inputs
Auxiliary Input Types & Ranges
Input
Type Ranges – Auxiliary Input A Input
Type Ranges – Auxiliary Input B
mA DC 0 to 20mA 4 to 20mA mA DC 0 to 20mA 4 to 20mA
0 to 5V 1 to 5V 0 to 5V 1 to 5V V DC
2 to 10V 0 to 10V
V DC
2 to 10V 0 to 10V
mV DC 0 to 100mV 10 to 50mV
Pot 2KΩ or higher
Auxiliary Input Performance
Input Sampling rate:
4 per second.
Input Resolution:
16 bit ADC.
Auxiliary Input
Scaling:
Scalable as a Remote Setpoint (RSP) input between –9999 and 10000,
constrained by the Setpoint Limits.
Measurement
Accuracy:
0.25% of input span 1 LSD.
