ProVU4 Controller, Profiler & Recorder/Controller - Product Manual
59407, Issue 1 – March 2008
Modbus Parameters
Page 87
Option Slot 1 Parameters
Parameter Name
Modbus Address
Access
Values
(Dec)
(Hex)
Value
Module Fitted In Slot 1
0
None Fitted
1
Single Relay
2
Single SSR Driver
3
Linear mA/V DC
8
Triac
Option Slot 1
Module Type
2130
0x0852
RO
255
Error (unrecognised module)
Value
Linear Output 1 Type
0
0 to 5V DC
1
0 to 10V DC
2
2 to 10V DC
3
0 to 20mA DC
4
4 to 20mA DC
Linear mA/V DC
Output 1 Type
2131
0x0853
R/W
5
Variable 0 to 10VDC Transmitter PSU
Value
Digital Output 1 Status
0
Inactive
Digital Output 1
Status
2132
0x0854
RO
1
Active
Linear Output 1
Level Status
2134
0x0856
RO
-2.0% to 102.0% of nominal range
(control output will over/under drive by 2%).
Value
Linear Output 1 Function
0
Disabled
1
Primary Output Power
2
Secondary Output Power
3
Retransmit Actual Setpoint Value
Linear Output 1
Function
2144
0x0860
R/W
4
Retransmit Process Variable Value
Value
Digital Output 1 Function
0
Disabled
1
Primary Output Power
2
Secondary Output Power
3
Alarm
Digital Output 1
Function
2146
0x0862
R/W
4
Alarm and Event
Value
Output 1 Alarm Selection
0
Alarm 1. Direct Acting
1
Alarm 1. Reverse Acting
2
Alarm 2, Direct Acting
3
Alarm 2. Reverse Acting
4
Alarm 3. Direct Acting
5
Alarm 3. Reverse Acting
6
Alarm 4. Direct Acting
7
Alarm 4. Reverse Acting
8
Alarm 5. Direct Acting
9
Alarm 5. Reverse Acting
10
OR of Alarm 1 or 2. Direct
Output 1 Alarm
Selection
2148
0x0864
R/W
11
OR of Alarm 1 or 2. Reverse
