48
ESC (F4) Exits from calibration and goes back to pH measurement mode
ENTER Confirms the calibration
Increases/decreases pH buffer reading
(Not functional)
2.5 Calibration Report
Calibration report gives you detailed information on calibration. It includes date
& time, buffer group, offset, temperature, number of days calibration is over due
and slope information.
2.5.1 To View Calibration Report:
1. From pH measurement mode, press left or right arrow key to navigate
to other available functions until you see REPO function in the LCD.
2. Press REPO (F2) key. The first page of calibration report is shown in the
display.
3. Press PAGE (F1) to view the second page of the report.
4. Press PRIN (F2) to transfer the calibration report to computer through IrDA.
Figure 19: pH Calibration Report
Example: In the given pH calibration report, 4-point calibration has been done
for USA buffer group (pH 1.68, pH 4.01, pH 7.00 & pH 12.45).
 The slope is 93 for the range enveloped from pH 1.68 to pH 4.01.
 The slope is 88 for the range enveloped from pH 4.01 to pH 7.00.
 The slope is 94 for the range enveloped from pH 7.00 to pH 12.45 where
pH 10.01 calibration point has been skipped.
Function Keys available in pH calibration report screen:
PAGE (F1) Goes to the second page of the calibration report
BACK (F1) Goes to the first page of the calibration report
PRIN (F2) Transfers calibration report to Computer through IrDA
