MFC010 Interface Manual 95
Appendix D : Sensor Sizes and Associated Default Register Settings
The available ranges and def ault settings of a num ber of the Holding registers (see section 7.5) depend
upon the sensor settings stored in Holding registers 1012, 1013 and 1014. The following table provides a
summary of t hese i nter-related v alues. W henever any of t he t hree s ensor s ettings are changed, the
associated defaults will be loaded. The Size setting will be set to its default value if the Sensor type is
changed, the Material setting will only be c hanged if the new sensor type does not support the current
Material setting.
NB. CAUTION
, Changing t he S ensor s ettings will ov erwrite t he f actory c alibration c oefficients C F1 t o
CF27 and the operational configuration.
Sensor Defaults
Type Size Material CF5
Pipe
Diameter Tube Amplitude
Maximum
Temperature
Minimum
Temperature
1012 1013 1014 3009 3043 1015 3097 3099
7000 06 Titanium 5500 5.53 mm 80% +150 °C - 40 °C
Hastelloy 5000 6.00 mm 80% +100 °C 0 °C
Stainless Steel 15000 5.53 mm 80% +100 °C 0 °C
10 Titanium 15000 8.56 mm 80% +150 °C - 40 °C
Hastelloy 37000 8.46 mm 80% +100 °C 0 °C
Stainless Steel 36000 8.40 mm 80% +100 °C 0 °C
15 Titanium 75000 14.80 mm 80% +150 °C - 40 °C
Hastelloy 150000 14.96 mm 80% +100 °C 0 °C
Stainless Steel 120000 14.96 mm 80% +100 °C 0 °C
Tantalum 100500 14.96 mm 80% +100 °C 0 °C
25 Titanium 160000 23.98 mm 80% +150 °C - 40 °C
Hastelloy 330000 24.28 mm 80% +100 °C 0 °C
Stainless Steel 290000 24.28 mm 80% +100 °C 0 °C
Tantalum 220000 24.28 mm 80% +100 °C 0 °C
40 Titanium 330000 36.28 mm 80% +150 °C - 40 °C
Hastelloy 640000 36.68 mm 80% +100 °C 0 °C
Stainless Steel 600000 36.68 mm 80% +100 °C 0 °C
Tantalum 455000 36.68 mm 80% +100 °C 0 °C
50 Titanium 550000 48.32 mm 60% +150 °C - 40 °C
Hastelloy 1000000 48.80 mm 60% +100 °C 0 °C
Stainless Steel 800000 46.26 mm 60% +100 °C 0 °C
Tantalum 760000 48.80 mm 60% +100 °C 0 °C
80 Titanium 1300000 68.80 mm 60% +150 °C - 40 °C
Hastelloy 2000000 70.23 mm 60% +100 °C 0 °C
Stainless Steel 1700000 70.23 mm 60% +100 °C 0 °C
3000 01 Hastelloy 83 1.20 mm 40% +150 °C - 40 °C
Stainless Steel 83 1.20 mm 40% +150 °C - 40 °C
03 Hastelloy 300 2.58 mm 40% +150 °C - 40 °C
Stainless Steel 300 2.58 mm 40% +150 °C - 40 °C
04 Hastelloy 620 3.94 mm 40% +150 °C - 40 °C
Stainless Steel 620 3.94 mm 40% +150 °C - 40 °C
