KROHNE MFC 010 C Converter - Manual (Page 70)

68
MFC010 Interface Manual
Register No. Description
3109 / 3110

CT
Calibration Coefficient #21
- One of the coefficients used to accurately calculate the values measured
by the sensor, defined during the manufacturing process.
Format : Floating Point
Range : 0.0 to 10
Default Value : 0
3111 / 3112

CT
Calibration Coefficient #22
- One of the coefficients used to accurately calculate the values measured
by the sensor, defined during the manufacturing process.
Format : Floating Point
Range : 0.0 to 10
Default Value : 0
3113 / 3114

CT
Calibration Coefficient #23
- One of the coefficients used to accurately calculate the values measured
by the sensor, defined during the manufacturing process.
Format : Floating Point
Range : 0.0 to 10
Default Value : 0
3115 / 3116

CT
Calibration Coefficient #24
- One of the coefficients used to accurately calculate the values measured
by the sensor, defined during the manufacturing process.
Format : Floating Point
Range : 0.0 to 10
Default Value : 0
3117 / 3118

CT
Calibration Coefficient #26
- One of the coefficients used to accurately calculate the values measured
by the sensor, defined during the manufacturing process.
Format : Floating Point
Range : 0.0 to 10
Default Value : 0
3119 / 3120

CT
Calibration Coefficient #27
- One of the coefficients used to accurately calculate the values measured
by the sensor, defined during the manufacturing process.
Format : Floating Point
Range : 0.0 to 10
Default Value : 0
3121 / 3122 2 Phase Warning level
- Defines the acceptable level of 2 phase signal. Set to zero to disable function
Format : Floating Point
Range : 0.0 to 1000.0
Default Value : 0
