A5-8
IM 01C50T02-01E
(12) LinkScheduleActivationVariable
Writing the version number of an LAS schedule,
which has already been downloaded to the domain,
to this parameter causes the corresponding
schedule to be executed. On the other hand,
writing 0 to this parameter stops execution of the
active schedule.
(13) LinkScheduleListCharacteristicsRecord
Sub-
index
Element
Size
[bytes]
Description
1 NumOf
Schedules
1 Indicates the total
number of LAS
schedules that have
been downloaded to
the domain.
2 NumOfSub
SchedulesPer
Schedule
1 Indicates the
maximum number
of sub-schedules an
LAS schedule can
contain. (This is fixed
to 1 in the Yokogawa
communication
stacks.)
3 ActiveSchedule
Version
2 Indicates the version
number of the schedule
currently executed.
4 ActiveSchedule
OdIndex
2 Indicates the index
number of the domain
that stores the
schedule currently
executed.
5 ActiveSchedule
StaringTime
6 Indicates the time
when the current
schedule began being
executed.
(14) DlmeScheduleDescriptor
This parameter exists for the same number as the
total number of domains, and each describes the
LAS schedule downloaded to the corresponding
domain. For the domain to which a schedule
has not yet been downloaded, the values in this
parameter are all zeros.
Sub-
index
Element
Size
[bytes]
Description
1 Version 2 Indicates the version
number of the LAS
schedule downloaded
to the corresponding
domain.
2 Macrocycle
Duration
4 Indicates the macro
cycle of the LAS
schedule downloaded
to the corresponding
domain.
3 TimeResolution 2 Indicates the time
resolution that is
required to execute
the LAS schedule
downloaded to the
corresponding domain.
(15) Domain
Read/write: impossible; get-OD: possible
Carrying out the GenericDomainDownload
command from a host writes an LAS schedule to
Domain.
