Yokogawa Wireless Temperature Transmitter YTA510 - Manual (Page 65)

A1-8
IM 01C50T02-01E
Relative
Index
Index Parameter Name
Default
(factory setting)
Write Description
13 2013 PRIMARY_VALUE
_TYPE_1
104 Auto Defines the type of primary value 1 (sensor 1
input). The following can be chosen for a YTA
transmitter:
104 = Process temperature
105 = Non process temperature
112 = mV
200 = ohm
14 2014 PRIMARY_VALUE
_1
— — Stores the value of the sensor 1 input.
15 2015 PRIMARY_VALUE
_RANGE_1
Sensor range — Defines the upper and lower range limits
and unit of PRIMARY_VALUE_1; differs
depending on the sensor selected.
16 2016 CAL_POINT_HI_1 — O/S Upper value for calibrations of sensor 1 input.
17 2017 CAL_POINT_LO_1 — O/S Lower value for calibrations of sensor 1 input.
18 2018 CAL_MIN_SPAN_1 Minimum span — Minimum calibration span for sensor 1 input.
19 2019 CAL_UNIT_1 mV or ohm — Unit of calibration value for sensor 1. Set to
"mV" for a thermocouple or mV input, or to
"ohm" for an RTD or resistance input.
20 2020 SENSOR_TYPE_1 As specified by the
customer before
shipment
O/S Type of sensor 1.
21 2021 SENSOR_RANGE_
1
Range of sensor — Range of sensor 1.
22 2022 SENSOR_SN_1 — O/S Serial number of sensor 1.
23 2023 SENSOR_CAL
_METHOD_1
103 Auto Calibration method for sensor 1:
103 = Factory trim standard calibration
104 = User trim standard calibration
24 2024 SENSOR_CAL_
LOC _1
— Auto Shows and is used to record the location
where sensor 1 was calibrated.
25 2025 SENSOR_CAL
_DATE_1
— Auto Shows and is used to record the date when
sensor 1 was calibrated.
26 2026 SENSOR_CAL
_WHO_1
— Auto Shows and is used to record the person who
calibrated sensor 1.
27 2027 SENSOR _
CONNECTION_1
As specified by the
customer before
shipment
O/S Number of connection wires of sensor 1.
28 2028 PRIMARY_VALUE
_TYPE_2
104 Auto Defines the type of primary value 2 (sensor 2
input). The following can be chosen for a YTA
transmitter:
104 = Process temperature
105 = Non process temperature
112 = mV
200 = ohm
29 2029 PRIMARY_VALUE_
2
— — Stores the value of the sensor 2 input.
30 2030 PRIMARY_VALUE_
RANGE_2
Sensor range — Defines the upper and lower range limits
and unit of PRIMARY_VALUE_2; differs
depending on the sensor selected.
31 2031 CAL_POINT_HI_2 — O/S Upper value for calibrations of the sensor 2
input.
32 2032 CAL_POINT_LO_2 — O/S Lower value for calibrations of the sensor 2
input.
33 2033 CAL_MIN_SPAN_2 Minimum span — Minimum calibration span for the sensor 2
input.
34 2034 CAL_UNIT_2 mV or ohm — Unit of calibration value for sensor 2. Set to
"mV" for a thermocouple or mV input, or to
"ohm" for an RTD or resistance input.
35 2035 SENSOR_TYPE_2 As specified by the
customer before
shipment
O/S Type of sensor 2.
