A1-12
IM 01C50T02-01E
Relative
Index
Index Parameter Name
Default
(factory setting)
Write Description
100 2100 LIMSW_4_VALUE_
D
— — Indicates the value and status of limit switch 4.
101 2101 LIMSW_4_TARGET 0 O/S Value to be monitored by limit switch 4. The
setting and the corresponding value are the
same as those for limit switch 1 (LIMSW_1_
TARGET).
102 2102 LIMSW_4
_SETPOINT
0 O/S Threshold of switching on limit switch 4
103 2103 LIMSW_4_ACT
_DIRECTION
0 (high-limit switch) O/S Type of limit switch 4. The setting and the
corresponding type are the same as those for
limit switch 1 (LIMSW_1_ACT_DIRECTION).
104 2104 LIMSW_4
_HYSTERESIS
0 O/S Hysteresis of limit switch 4. Input of only a
positive number is valid.
105 2105 LIMSW_4_UNIT — — Unit of LIMSW_4_SETPOINT and LIMSW_4_
HYSTERESIS
106 2106 DISPLAY_AI_OUT 0 (AI1 only) Auto Selects the AI block or blocks whose values
are to be displayed on the LCD:
0 = AI1
1 = AI2
2 = AI3
3 = AI4
4 = AI1, AI2
5 = AI1, AI2, AI3
6 = AI1, AI2, AI3, AI4
107 2107 DISPLAY_ERROR 0 (SHOW) Auto Whether to display error codes on the LCD:
0 = SHOW
1 = INHIBIT
108 2108 DISPLAY
_WARNING
1 (INHIBIT) Auto Whether to display warning codes on the LCD:
0 = SHOW
1 = INHIBIT
109 2109 DISPLAY
_ADDRESS
1 (INHIBIT) Auto Whether to display the device address on the LCD:
0 = SHOW
1 = INHIBIT
110 2110 DISPLAY_CYCLE 2 Auto Display refresh cycle (2 to 255 seconds)
111 2111 WARNING_
ENABLE _1
Depends on the
specification upon
shipment
Auto Switches on and off generation of warnings
corresponding to DEVICE_STATUS_5 of the
resource block.
112 2112 WARNING_
ENABLE _2
Depends on the
specification upon
shipment
Auto Switches on and off generation of warnings
corresponding to DEVICE_STATUS_6 of the
resource block.
113 2113 WARNING_
ENABLE _3
Depends on the
specification upon
shipment
Auto Switches on and off generation of warnings
corresponding to DEVICE_STATUS_7 of the
resource block.
114 2114 WARNING_
ENABLE _4
Depends on the
specification upon
shipment
Auto Switches on and off generation of warnings
corresponding to DEVICE_STATUS_8 of the
resource block.
115 2115 MODEL YTA320 — Model code of the transmitter
116 2116 YTA_OPTION Depends on the
specification upon
shipment
— Option of the transmitter
A1.5 Unit and Code
Unit Code
K 1000
°C 1001
°F (Note) 1002
°R (Note) 1003
mV 1243
ohm 1281
Note : Available only when option /D2 is specified.
