NANO-945GSE EPIC Motherboard

Page 7

SATA

Two 1.5 Gbps SATA drives supported

Keyboard/mouse

One external PS/2 connector

Parallel Port

One 26-pin parallel port connector

Expansion

One PCI-104 expansion slot (PCI bus)

One PCIe mini card (PCIe bus)

Digital I/O

One 8-bit digital input/output connector; 4-bit input/4-bit

output through the ITE IT8718 super I/O

Watchdog Timer

Software programmable 1-255 sec. through the ITE IT8718

super I/O

Infrared

One infrare connector through the ITE IT8718 super I/O.

Supports:

Serial Infrared (SIR)

Amplitude Shift Keyed IR (ASKIR)

Power Supply

ATX and AT power supported

Power Consumption

12V @ 1.53 A

(

1.6 GHz Intel® Atom™ one 2.0 GB DDR2 SO-DIMM

)

Temperature

0ºC – 60ºC (32ºF - 140ºF)

Humidity (operating)

5%~95% non-condensing

Dimensions (LxW)

115mm x 165mm

Weight (GW/NW)

700g/350g

Table 1-1: Technical Specifications
