5.6.2 Motherboard Installation
To install the NANO-945GSE motherboard into the chassis please refer to the reference
material that came with the chassis.
5.7
I
nternal Peripheral Device Connections
5.7.1 Peripheral Device Cables
The cables listed in
850H903H
Table 5-9 are shipped with the NANO-945GSE.
Quantity
Type
1
Keyboard and Mouse cable
2
SATA drive cable
1 Power
cable
1 RS-232
cable
Table 5-9: IEI Provided Cables
Some optional items that can be purchased separately and installed on the
NANO-945GSE include:
Dual port USB cable
Parallel port cable
RS-232/422/485 cable
ATX power cable
