NANO-945GSE EPIC Motherboard
Page 6
Front Side Bus (FSB) 533 MHz
System Chipset
Northbridge: Intel® 945GSE
Southbridge: Intel® ICH7-M
Memory
One 200-pin SO-DIMM socket supports one 533 MHz 2.0
GB (max.) DDR2 SDRAM SO-DIMM
CompactFlash® One CompactFlash® Type II socket
Super I/O ITE IT8718
Display
Intel® Generation 3.5 integrated GFX core (133 MHz)
HDTV with 1080i maximum resolution supported
Dual LVDS support
18-bit dual channel LVDS integrated in Intel® 945GSE
NANO-945GSELVDS2: 18/24-bit dual-channel supported
with CH7308
BIOS AMI BIOS label
Audio
5.1 channel audio kit with Realtek ALC655 AC'97 codec
7.1 channel HD audio kit with Realtek ALC883 codec
supports dual audio streams
LAN Two Realtek RTL8111CP GbE controllers
COM
Three RS-232 serial ports
One RS-232/422/485 serial port
USB2.0
Six USB 2.0 devices supported:
Four by onboard pin-headers
Two by external connectors
Hard Drives
One 44-pin IDE connector connects to two Ultra
ATA33/66/100 devices
