Figure 5-12: Connect Power Cable to Power Supply

5.7.3 5.1 Channel Audio Kit Installation

NOTE:

This is an optional item that must be ordered separately. For further

information please contact the nearest NOVA-9452 distributor, reseller

or vendor or contact an iEi sales representative directly. Send any

queries to

353H

The optional 5.1 channel audio kit connects to the 10-pin audio connector on the

NOVA-9452. The audio kit consists of three audio jacks. One audio jack, Mic In, connects

to a microphone. The remaining two audio jacks, Line-In and Line-Out, connect to two

speakers. To install the audio kit, please refer to the steps below:
