KINO-DQM871 Mini-ITX SBC

Page 33

Pin Description Pin

Description

1 PCIE_WAKE#

2

VCC3

3 N/C

4

GND

5 N/C

6

1.5V

7 N/C

8

N/C

9 GND

10 N/C

11 CLK-

12

N/C

13 CLK+

14

N/C

15 GND

16

N/C

17 PCIRST#

18

GND

19 N/C

20

VCC3

21 GND

22

PCIRST#

23 PERN2

24

3VDual

25 PERP2

26

GND

27 GND

28

1.5V

29 GND

30

SMBCLK

31 PETN2

32

SMBDATA

33 PETP2

34

GND

35 GND

36

USBD-

37 N/C

38

USBD+

39 N/C

40

GND

41 N/C

42

N/C

43 SATA_DET4_R_N

44

N/C

45 N/C

46

N/C

47 N/C

48

1.5V

49 N/C

50

GND

51 MSATA_SEL# 52

VCC3

Table 3-16: PCIe Mini Card Slot Pinouts

3.2.15 PCI Express x16 Slot

CN Label:

PCIEX16_1

CN Type:

PCIe x16 slot
