KINO-DQM871 Mini-ITX SBC
Page 93
Enabled D EFAULT Legacy USB support enabled
Disabled Legacy USB support disabled
Auto Legacy USB support disabled if no USB devices are
connected
5.3.9 iWDD H/W Monitor
The iWDD H/W Monitor menu (BIOS Menu 11) displays the CPU temperature and CPU
fan speed, and contains the fan configuration submenu.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
PC Health Status
CPU temperature : +68 C
> Smart Fan Mode Configuration
Smart Fan Mode Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 11: iWDD H/W Monitor
PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
CPU Temperature
5.3.9.1 Smart Fan Mode Configuration
Use the Smart Fan Mode Configuration submenu (BIOS Menu 12) to configure the
smart fan temperature and speed settings.
