5.3.11.1 Smart Fan Mode Configuration
Use the Smart Fan Mode Configuration submenu (BIOS Menu 16) to configure fan
temperature and speed settings.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
CPU_FAN1 Smart Fan Control [Auto Duty-Cycle Mode]
CPU Temperature 1 60
CPU Temperature 2 50
CPU Temperature 3 40
CPU Temperature 4 30
SYS_FAN1 Smart Fan Control
[Auto Duty-Cycle Mode]
System Temperature 1 60
System Temperature 2 50
System Temperature 3 40
System Temperature 4 30
Smart Fan Mode Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 16: Smart Fan Mode Configuration
CPU_FAN1/SYS_FAN1 Smart Fan Mode [Auto Duty-Cycle Mode]
Use the FAN1/FAN2 Smart Fan Mode option to configure the system smart fans.
Manual Duty
Mode
The fan spins at the speed set in Manual Duty
Mode settings (below option)
Auto by
Duty-Cycle
Mode
D EFAULT The fan adjusts its speed using Auto by
Duty-Cycle settings
CPU/System Temperature n
Enter a decimal number between 1 and 100 to change the fan CPU/System Temperature
n value.
