Connector Type Label
SATA power connectors 4-pin wafer SATA_PWR1,
SATA_PWR2
SMBus connector 4-pin wafer SMB1
SO-DIMM connectors SO-DIMM connector DIMM1, DIMM2
SPI Flash connector 6-pin wafer SPI1
SPI Flash connector (EC) 6-pin header JSPI1
TPM connector 20-pin header TPM1
USB 2.0 connectors 8-pin header USB1, USB2, USB3
USB 3.0/2.0 connector 20-pin box header CN1
Table 3-1: Peripheral Interface Connectors
3.1.3 External Interface Panel Connectors
The table below lists the rear panel connectors on the KINO-DQM871. Detailed
descriptions of these connectors can be found in a later section.
Connector Type Label
Audio jacks (mic-in, line-out) Audio jack AUDIO1
Ethernet and USB 2.0 connectors RJ-45 and USB 2.0 LAN2_USB2
Ethernet and USB 3.0 connectors RJ-45 and USB 3.0 LAN1_USB1
HDMI connectors HDMI HDMI1, HDMI2
Power connector 4-pin DIN PWR1
RS-232 serial port D-sub 9 COM1
VGA connector D-sub 15 VGA1
Table 3-2: Rear Panel Connectors
