3.7.4. Timing an OPEN-CLOSE-OPEN Operation
To time an OPEN-CLOSE-OPEN operation:
a. Start from the “START-UP” menu:
Press the [1] key (TIME BREAKER) to start a test.
b. The following screen will be displayed:
Press the [1] key (NO).
c. The following screen will be displayed:
Press the
[1]
key (WINDOW = 1 SEC) to select the 1-second timing window.
d. The following screen will be displayed:
Press the
[1]
key (INTERNAL TRIGGER) to select the internal trigger.
TRIGGER MODE:
1. INTERNAL TRIGGER
2. EXTERNAL TRIGGER
TIMING WINDOW:
1. WINDOW = 1 sec
2. WINDOW = 10 SEC
3. WINDOW = 20 SEC
INSERTION RESISTOR?
1. NO
2. YES
1. TIME BREAKER
2. GET RESULTS
3. SETUP
4. DIAGNOSTICS
