Vanguard DigiTMR S2 - Manual (Page 18)

DIGITMR S2 USER’S MANUAL REV 1
13
The DigiTMR S2 will be listed as “DigiTmr S/N” where S/N is the device’s serial number.
Click on the icon for the DigiTMR and then click on the “Next” button.
d. The following window will be displayed asking for a secret key to connect to the
DigiTMR S2:
Type the word “default” (without the quotes and in all lower-case) and then click on the
“Next” button.
e. The following window will be displayed with the option to connect to the DigiTMR S2 as
a serial port:
Make sure to check the box next to “AT Serial” and then click on the “Next” button.
f. The following confirmation screen will be displayed:
