REV 1 DIGITMR S2 USER’S MANUAL
54
e. The following screen will be displayed:
Press the
[4]
key (C-O) to select the CLOSE-OPEN timing operation.
f. The following screen will be displayed:
Press the
[1]
key (Contact #1 CLOSE).
NOTES
Option details
• Contact #1 CLOSE
The open operation is initiated after contact channel #1 is closed. If this
option is selected, the DigiTMR S2 will first initiate a CLOSE command
and then send an OPEN command only when it detects that the main
contact #1 is closed. This mode accurately simulates the closing of a
breaker on a fault condition.
• Set DELAY
A delay from 10 to 500 milliseconds can be set between the CLOSE and
OPEN command. When a delay is used in the operation, it may not
represent a true breaker operating condition.
• No DELAY
Both the CLOSE and OPEN commands are initiated by the DigiTMR S2
simultaneously.
g. The following screen will be displayed:
HOLD "ARM" UNTIL
TEST COMPLETES
"START" TO BEGIN
"STOP" TO ABORT
C-O SECOND TRIGGER
1. CONTACT #1 CLOSE
2. SET DELAY
3. NO DELAY
TIMING MODE:
1. OPEN 2. CLOSE
3. O-C 4. C-O
5. O-C-O
