3.4.2. Setting the Measurement Units

The DigiTMR S2 supports both English and Metric calculations from the breaker’s travel
parameters. Follow the steps below to change the measurement units:

e. Start from the “START-UP” menu:

Press the

[3]

key (SET-UP).

f. The following screen will be displayed:

Press the

[2]

key (MEASUREMENT UNITS).

g. The following screen will be displayed:

NOTE

When the measurement units are changed, the DigiTMR S2 will re-calculate
the velocity and convert the readings of test shots to the new measurement
units. For example, if a test shot was taken using the English measurement
units and then the units of measure is changed to Metric, the velocity and test
readings will be automatically converted to Metric.

1. ENGLISH

Press the

[1]

key (ENGLISH) for English measurement units. The measurement

units will be set to English, and you will be returned to the “START-UP” menu.

SELECT UNITS
1. ENGLISH
2. METRIC
3. ROTARY ENCODER

1. ANALYSIS POINTS
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. SHOT DESCRIPTION
5. NEXT PAGE

1. TIME BREAKER
2. GET RESULTS
3. SETUP
4. DIAGNOSTICS
