3.4.5. Setting the Frequency

Follow the steps below to set the frequency (50 or 60 Hz):

a. Start from the “START-UP” menu:

Press the

[3]

key (SET-UP).

b. The following screen will be displayed:

Press the

[5]

key (NEXT PAGE).

c. The following screen will be displayed:

Press the

[3]

key (SET 50/60 HZ).

d. The following screen will be displayed:

Select the preferred frequency by pressing the corresponding key on the keypad (

[1]

for

50 Hz or

[2]

for 60 Hz). The frequency will be set and the following confirmation screen

will be displayed:

1. SET 50 HZ
2. SET 60 HZ

1. SET DATE & TIME
2. SET PRINT MODE
3. SET 50/60 HZ
4. SET LANGUAGE
5. BLUETOOTH DEV RESET
6. PREVIOUS PAGE

1. ANALYSIS POINTS
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. SHOT DESCRIPTION
5. NEXT PAGE

1. TIME BREAKER
2. GET RESULTS
3. SETUP
4. DIAGNOSTICS
