c. The following screen will be displayed:

Press the

[1]

key (OPEN TIMING)

NOTE

If you would like to see the current AP1 and AP2 settings, press the

[3]

key

(PRINT SETTINGS). The settings will be printed on the thermal printer, and you
will be returned to the “START-UP” menu.

d. The following screen will be displayed:

Press the

[2]

key (DIST FROM CLOSE)

NOTES

Option details

• PERCENT OF STROKE

Percent of stroke is the distance based on the percentage of the total
breaker’s stroke distance. The distance is always measured from the
starting point at the fully closed position of the breaker contacts.

• DIST FROM CLOSE

The distance from Close range is selectable from 00.0 inch to 99.99
inches or from 0.0 centimeter to 99.90 centimeters. The distance is
referenced from the contact’s closed position.

• CONTACT #1

Contact point is the distance from the contact’s closed position to the
point where it is in transition from the close-to-open or the open-to-
close position. Contact channel #1 is used for this option.

OPEN ANALYSIS PT 1

1. PERCENT OF STROKE
2. DIST FROM CLOSE
3. CONTACT #1

1. OPEN TIMING
2. CLOSE TIMING
3. PRINT SETTINGS
4. TEST PLANS
