REV 1 DIGITMR S2 USER’S MANUAL

h. The following screen will be displayed:

Press the

[1]

key (Internal Trigger) to select the internal trigger.

i. The following screen will be displayed:

Press the

[1]

key (OPEN) to select the OPEN timing operation.

j. The following screen will be displayed:

Press and hold down the

[ARM]

switch, and then press the

[START]

key. Continue to

hold down the

[ARM]

switch.

k. The following screen will be displayed during testing:

Continue to hold down the

[ARM]

switch until the test is completed.

l. Once the test is completed, you will be returned to the “START-UP” menu.

Please see section 3.9 for instructions on how to print the test results.

TEST IN PROGRESS
HOLD "ARM" UNTIL
TEST COMPLETES.
(UP TO 25 SECONDS)

HOLD "ARM" UNTIL
TEST COMPLETES

"START" TO BEGIN
"STOP" TO ABORT

TIMING MODE:

1. OPEN 2. CLOSE
3. O-C 4. C-O
5. O-C-O

TRIGGER MODE:

1. INTERNAL TRIGGER
2. EXTERNAL TRIGGER
