background image

APPENDIX B: MASTER WORKSHEETS

This appendix contains blank master worksheets for photocopying. Entries are not made on the
master worksheets. FCS wirelist entries are entered on the applicable photocopied worksheets, as
determined by the FCS modules used to build the control strategy (it is not necessary to make pho-
tocopies of all of the master worksheets to build a Flexible Control Strategy).

The master worksheets presented in this section contain the input modules (ANI, CCI, and SDT1,)
followed by the other FCS modules in datapoint numeric order (e.g., B100 through B239). The in-
put modules do not have any assigned FCS datapoints, as they are the modules that initially ac-
cept signals external to the PCS. It is their outputs that are connected to the input datapoints of
the other FCS modules.

The FCS module order presented in the master worksheets is as follows:

Applicable

Loop Number

1, 2, 4

Datapoint

Range

FCS Module

1, 2, 4

N/A

ANI Load Input

1, 2, 4

N/A

CCI Load Input

1, 2, 4

N/A

SDT1 Load Input

1, 2, 4

B100 - B104

ANO Load Output

1 ,2, 4

B105 - B110

CCO Load Output

1, 2, 4

B111 - B118

SDT0 Load Output

1

B119 - B122

Extended Math A

1

B123 - B126

Math A

1

B127 - B129

Logic A

1

B130 - B132

Logic B

1

B133 - B135

Parameter Loader A

1

B136 - B138

Parameter Loader B

1

B139 - B141

Parameter Loader C

1

B142 - B144

Parameter Loader D

1

B145 - B147

Parameter Loader E

1

B148 - B151

Setpoint Generator 0

1

B152 & B153 Deviation/Alarm 0

1

B154 - B157

PID 0

1

B158 - B161

Auto/Manual Switch 0

1

B162 - B165

Math B

1

B166 - B169

Math C

1

B170 - B172

Logic C

2

B173 - B176

Extended Math B

2

B177 - B180

Math D

2

B181 - B183

Logic D

2

B184 - B186

Logic E

2

B187 - B190

Setpoint Generator 1

2

B191 & B192 Deviation/Alarm 1

2

B193 - B196

PID 1

Appendix B. Master Worksheets

ENTRIES

B-1
