Table A-9. CS40 Wirelist
EXTENDED MATH A
ONE LOOP COMMENTS:
W/L DEFLT VALUE NAME
B119 255 A K12
C365
0
K11
C364
0
K10
C363
0
K9
C362
0
K8
C361
0 B120 254 B
B121 253 C K1
C354
0
K2
C355
0
K3
C356
0
K4
C357
0
K5
C358
0
K6
C359
0
K7
C360
0 B122 000 FC
MATH A
ONE LOOP COMMENTS: K1 = 1 FOR C076, K2 = -1 FOR C077
W/L DEFLT VALUE NAME
B123 076 (C) 173 A
B124 077 (C) 184 B
B125 078 (C) 185 C K1
C076
1
K2
C077
-1
K3
C078
0 B126 000 005 FC
LOGIC A
ONE LOOP COMMENTS:
W/L DEFLT VALUE NAME
B127 097 (L) 156 A
B128 097 (L) 107 B
B129 000 002 FC
LOGIC B
ONE LOOP COMMENTS:
W/L DEFLT VALUE NAME
B130 096 A
B131 096 B
B132 000 FC
PARAMETER LOADER A
ONE LOOP COMMENTS:
W/L DEFLT VALUE NAME
B133 070 A
B134 070 B
B135 255 C
