Luminex 100 IS User Manual Version 2.1
x
MAP Technology
5 - 10
PN 89-00002-00-070 Rev. A
XYP Instrument
Sample Probe
A stainless steel Sample Probe acquires a sample. A shorter probe is
provided for shipping and troubleshooting.
Cheminert
®
Fitting
This fitting may be disconnected to allow replacement of the Sample
Probe as necessary.
This guides the Sample Probe into the XYP instrument.
Figure 27. Cheminert Fitting
Warning:
During operation, this system contains exposed moving
parts that result in puncture hazard. Risk of personal injury is
present. Keep hands and fingers away from the Sample Probe.
The shield should be in place.
XYP sampling probe (see
Alignment guide
Cheminert fitting
Shield
Sample arm
