Luminex 100 IS User Manual, Version 2.1 User Manual
Page 36
Luminex 100 IS User Manual Version 2.1
x
MAP Technology
4 - 8
PN 89-00002-00-070 Rev. A
Figure 20. The XYP Instrument Sampling Probe
6. Re-install the light housing by pushing until it snaps into place.
7. Install the shield to cover the sampling probe area. This shield
should only be removed for making adjustments to the probe.
Figure 21. The Clear Plastic Shield
