3 - 15
Table 3-8 Default Traverse Length Control Parameters
CP Parameter Name Parameter Value
CP-02 Traverse Length 1 0.000
CP-04 Traverse Length 2 0.000
CP-06 Traverse Length 3 0.000
CP-08 Traverse Length 4 0.000
Table 3-9 Entering Traverse length Control Parameters
CP Parameter Name Parameter Value
CP-02 Traverse Length 1 In a level wind application, enter your reel length in
E.U.s (reference Setpoint 1).
In a web scanning operation, enter the width of your
web, in E.U.s (reference Setpoint 1).
CP-04 Traverse Length 2 In a level wind application, enter your reel length in
E.U.s (reference Setpoint 2).
In a web scanning operation, enter the width of your
web, in E.U.s (reference Setpoint 2).
CP-06 Traverse Length 3 In a level wind application, enter your reel length in
E.U.s (reference Setpoint 3).
In a web scanning operation, enter the width of your
web, in E.U.s (reference Setpoint 3).
CP-08 Traverse Length 4 In a level wind application, enter your reel length in
E.U.s (reference Setpoint 4).
In a web scanning operation, enter the width of your
web, in E.U.s (reference Setpoint 4).
