CONTREX M-Traverse User Manual
Page 125
3 - 78
Characters 5,6 - Parameter Number:
The Control Parameter Code is sent back to the host computer from the
M–Traverse.
Characters 7 through 14 - DATA:
The Control Parameter or Monitor Variable data that was requested is sent back to
the host computer from the M–Traverse.
For an interpretation of the MV-50 through MV-56 data, refer to
Table 3-43. For the ASCII to binary conversion, refer to Table 3-42.
Character 15 - Data Format:
Character 15 indicates the decimal location and polarity of the data that was
transmitted in characters 7 through 14.
Use the following codes to indicate decimal location and polarity:
Code
Format
0
+XXXXXX
1
+XXXXX.X
2
+XXXX.XX
3
+XXX.XXX
4
+XX.XXXX
5
+X.XXXXX
6
-XXXXXX.
7
-XXXXX.X
8
-XXXX.XX
9
-XXX.XXX
:
-XX.XXXX
;
-X.XXXXX.
Character 16 - ETX:
The return message is always terminated with the ASCII “ETX” character.
