3 - 61
MV-52 CONTROL STATE
The digit that displays a number “1” is the active control state of the M–Traverse. In the
example below, “Run” is the active control state.
Jog
Run (Follower/Direct)
Home Return
Home Seek
F-Stop
Wait is Active
MV-58 INVALID PROFILE
If a profile entry has been rejected, the Invalid Profile parameter will display the reason
that it was rejected. The M–Traverse will not allow your system to enter "Run" if there
is an invalid profile. The digit that displays a number “1” is the error. In the example
below, “The process length is zero or negative” is the error.
Lead Size or Follower Size > 14,400,000
Process length is either zero or negative
Not Used
Not Used
Not Used
Not Used
