3 - 60
STATUS MONITORING
These MVs monitor the status of the M–Traverse's modes of operation and operating
states.
MV-50 KEYPAD ERROR
If a Control Parameter entry has been rejected, Keypad Errors will display the reason
that it was rejected. The digit that displays a number “1” is the error. In the example
below, “Value Exceeds Maximum Limit” is the error.
Invalid Code Parameter
Value Exceeds Maximum Limit
Value Below Minimum Limit
Keypad Lockout Enabled
Lockout During Run State or Entry Timeout
Not Used
MV-51 ALARM STATUS
The digit that displays a number “1” is the active Alarm. In the example below, “High
Speed Alarm ” is the active alarm.
Home Not Defined
High Speed Alarm
Forward or Reverse Limit Alarm
Not Used
Not At-Home
Not Used
