5 - 38
APPENDIX E: MONITOR VARIABLE
REFERENCE
CODE DESCRIPTION MIN MAX UNITS
MV-40 Tach-Velocity -3600 3600 RPM
MV-41 Lead Frequency -99999 120000 Hz
MV-42 Feedback Frequency -99999 120000 Hz
MV-43 Lead Position -99999999 536000000 Lines
MV-44 Follower Position -99999999 536000000 Lines
MV-45 Follower Position E.U. -99999 999999 E.U.
MV-46 Product Rate 0.0 9999.9 Cycles/Min
MV-47 DAC Output -4095 4095 DAC Bits
MV-48 Trim Output -4095 4095 DAC Bits
MV-49 Position Error -99999999 536000000 Lines
MV-50 Keypad Errors 0 011111 Coded
MV-51 Alarm Status 0 010111 Coded
MV-52 Control State 1 110000 Coded
MV-53 Discrete Inputs-Group A 0 111111 Coded
MV-54 Discrete Inputs-Group B 0 111011 Coded
MV-55 Discrete Inputs-Group C 0 001111 Coded
MV-56 Discrete Outputs-Group A 0 111111 Coded
MV-57 Discrete Outputs-Group B 0 000001 Coded
MV-58 Invalid Profile 0 000011 Coded
MV-59 Line Notch Counter 0 999999 Coded
MV-74 Com Errors 0 11111 Coded
MV-80 Lead Job Size 0 536000000 Lines
MV-81 Foll Job Size 0 536000000 Lines
MV-84 Foll Profile Length 0 536000000 Lines
MV-86 Process Ratio 0.0000 10.0000 Ratio
MV-87 Profile Ratio 0.0000 10.0000 Ratio
MV-89 Batch Count 0 9999 Counts
MV-99 Software Code Revision — — —
MV-00 Software Part Number — — —
