CONTREX M-Traverse - Manual (Page 21)

2 - 6
,
,
M-TRAVERSE
3.6"
7.2"
7.5"
5.7"
3.9"
,
,
DOOR PANEL (
3.65" .03"
CUTOUT
(
CUTOUT
7.25" .03" ( )
Contrex
Contrex
Set
Figure 2-4 M–Traverse Mounting and Cutout Dimensions
