4 - 8
Input Test #7 - To Test the Discrete Inputs
To enter this test, press the “Status” key to increment (or the “Tach” key
to decrement) until the number “7” is visible on the right side of the
upper LED display.
Press “Enter” to start the test.
The lower LED display will remain blank unless an input has been
shorted to common. If an input has been shorted, it's number will
display. For example, if the number four appears in the display, then F–
Stop has been shorted. To test an input, short that input and open all of
the other inputs.
Input Closure Display
NOT USED (J3-10) 10
HOME SYNC (J3-12) 11
SETPOINT SELECT A (J3-13) 12
SETPOINT SELECT B (J3-15) 13
HOME SET (J3-16) 14
HOME SEEK (J4-2) 15
HOME RETURN (J4-3) 16
BATCH RESET (J4-5) 17
RUN (J4-6) 02
WAIT (J4-8) 03
F-STOP (J4-9) 04
KEYLOCK (J4-11) 05
FWD LIMIT (J4-12) 06
REV LIMIT (J4-14) 07
JOG FWD/REV (J4-15) 01
JOG (J4-17) 00
Press “Clear” to exit the test.
Press “Code Select” only if you want to exit diagnostics.
